ASROCK 890FX Deluxe5

Motherboard higher consumer class designed to create a luxuriously powerful gaming stations with many unique features and numerous and varied interfaces.As one of the first in the market has a new socket AM3 +, which is intended for the new 32nm AMD processors and is backward compatible with socket AM3 processors to.You get the possibility of fitting simultaneously 6jádrových most powerful range of processors from AMD Phenom II X6 even 8jádrových future.A distinctive feature of the plate is a high number of slots 3 PCI Express x16, which currently allows connection of up to three graphics cards manufacturers ATI/AMD CrossFireX mode.You can even connect two parallel Two-chip graphics card.
When designing plates were used only highly conductive polymer capacitors gold ASRock DuraCap highest quality.Their advantage over conventional capacitors is 2.5 times longer life skills and self-repairing polymer layer.The board also excels in advanced power system for a processor consisting of 8 +2 phases.It is obvious that is suitable for users dealing with overclocking.Another unique feature of this model is calledC.C.O.(Combo Cooler Option) which will please you if you have an old CPU heatsink compatible with socket LGA 775 and LGA 1156 and still do not want him to say goodbye.C.C.O.is allowing its use in the socket LGA 1155, which this board has.
Users who revel in the monitoring system and its possibilities for growth performance, will appreciate the special software ASRock Extreme Tuning Utility.AXTU is executed in a user-friendly interface in one place and provide hardware monitoring functions, speed, fan speed, temperatures and the possibility of overclocking.It is worth mentioning EFI BIOS unprecedented graphical user interface that can handle the new mouse movements.EFI bios also breaks the boundary of the operating system boot disks smaller than 2 TB.Now you can start the OS from a single large disk without fractionation capacity of up to 3 TB!
The support of the latest technology USB data transfer 3rd0 and SATA III.In the third case, a USB0 board streamlines the ultra-fast data transfer via unique technology ASRock XFast USB, which promises up to 335% faster data transfer compared to motherboards without this technology to bring the world's fastest USB data retrieval and saves.USB third0 ports will be available on the rear panel of 4 and in addition you will be able to develop additional 4 USB third0 ports on the front panel of the rear rack with the supplied plugs and "drawer" with the possibility of keeping 2.5 "SSD/HDD.
USB is on the rear panel supplemented with additional ports not commonly Vidana Firewire, eSATA III digital and analog audio outputs of the internal sound chip specifications THX TruStudio PRO.An interesting feature is the CMOS reset button, which is used to quickly erase the BIOS setup if it would suit you for overclocking.
Specifications:
Supported processors: Series:AMD Phenom II X6/X4/X3/X2 (except models 920/940)/Athlon II X4/X3/X2/Sempron Base:AM3 + Power system:8 +2 phase
FSB:
2600 MHz (5.2 GT/s)
Chipset:
North Bridge:AMD 890FX
South Bridge:AMD SB850
Memory:
Type:DDR3
Slot:2x DIMM
Frequency:800/1066/1333/1600 (OC)/1800 (OC)/1866 (OC) MHz
Connection mode:Dual-channel
Max.capacity:32 gigabytes
Video:
The need for a separate graphics card
Support for ATI Quad CrossFireX, 3-Way CrossFireX CrossFireX
Audio:
Realtek ALC892
7th1 HD
THX FOR TruStudio
LAN:
Realtek RTL8111E
10/100/1000 Mbit/s
Expansion Slots:
3x PCI Express 2nd0 x16 (x16 + 1x 2x x4)
2x PCI Express 2nd0 x1
2x PCI
Internal interface:
8x SATA III (6 Gbit/s RAID Intensity 0/1/0 +1/5)
1x USB third0 connector (2 additional USB thirdPorts 0)
2x USB 20 connector (4 additional USB 2Ports 0)
1 x COM connector
1x FDD
1 IR connector
1x Firewire connector
HDMI_S 1/PDIF out connector
External interfaces:
2x PS/2 (mouse, keyboard)
2x USB third0
6x USB 20
1x eSATA III
1x Firewire
1x RJ-45
6 x audio jacks
1 x coaxial S/PDIF
1 x optical S/PDIF
1 CMOS reset button
Power:
1x ATX 24pinový
1x 8-pin ATX 12V connector
Design:
ATX
Dimensions:
30.5 x 24.4 cm
Included accessories:
Installation CD
User Manual
Anti-virus software (trial version)
Software CyberLink DVD Suite (trial version)
Rear Panel
4x SATA data cable
2 x SATA power cable
1x IDE Cable
1x front panel with USB third0
4 screws for HDD
6x chassis screws
1 x rear USB third0 Shield
