Socket and chipset
Socket
AMD FM2+
Chipset
AMD A58
Format & functions
Motherboard form factor
mATX (Micro ATX)
Basic functions
Integrated network card, Integrated sound card, PCI Express 3.0
Memory
Memory type
DDR3
Number of RAM slots
2 ×
Max. frequency (OC)
1,866 MHz
Connection Mode
dual-channel
Advanced parameters
Advanced features
RAID controller, AMD Dual Graphics
Sound card type
Realtek ALC662
Number of sound card channels
5.1
Connectors
External
DVI, Jack, PS/2, USB 2.0, VGA (D-Sub)
Internal
COM header, Front Panel Audio connector, Serial ATA II, TPM header, USB 2.0 header
PCI express x16
1×
PCI express x1
1×
USB 2.0
6×
Serial ATA II
6×
PCI
1×
